Nc Servo Punch Feeder Hardware Parts Machining Accuracy Straightening Metal

Name: Nc Servo Punch Feeder Hardware Parts Machining Accuracy Straightening Metal
Brand: RUIHUI
Price: 1 USD

China Nc Servo Punch Feeder Hardware Parts Machining Accuracy Straightening Metal wholesale

Brand Name : RUIHUI

Certification : CE, ISO certification

Place of Origin : Guangdong, China (Mainland)

MOQ : 1 Set

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 30 Sets Per Month

Delivery Time : 30 work days

Packaging Details : Wooden Box or Vacuum Packing

Stock Width(mm) : 50-400

Stock Thickness(mm) : 0.3-4.5

Line Speed(m/min) : 16~24

Coil Weight(Kg) : 5000

Main Motor(Kw) : AC 4.4

Warranty Period : 12 Months

Trademark : RUIHUI

Max.Coil O.D.(mm) : 1400

Function : Electric Hydraulic Hole Puncher

Type : Straightener Feeder & Uncoiler

Use : Sheet

After-sales Service Provided : Engineers available to service machinery overseas

Contact Now

Punch Feeder, Hardware Parts Machining Accuracy, Straightening Metal (MAC3-400)

http://www.ruihui.net

1. The scale of the primary standard of the punch feeder should be compatible with the processing scale of the workpiece. That is, small workpieces should be selected with small standard active feeders, while large workpieces should be selected with large standard active feeders to make reasonable use of the equipment.
2. The working accuracy of the punch feeder is adapted to the processing accuracy of the process request. According to the processing precision of the parts, the feeder is requested. If the rough machining process with low precision request is selected, the feeder with low precision should be selected, and the precision machining process with high precision request should be selected with high precision feeder.

3. The variety of feeders depends on the standard size of the machine tool, the type of punching machine, the type of punching machine, the weight of the workpiece, and so on. There are too many varieties of punching machines in the mall.

Motor stator and rotor special yaw feeder, automatic swing feeder free installation and commissioning; metal stamping, cap factory, auto parts, cabinet beam, shovel, coil, steel belt, furniture.
Nc Servo Punch Feeder Hardware Parts Machining Accuracy Straightening Metal

Specification:

Model	MAC2-400	MAC2-500	MAC2-600		MAC2-800
Stock Width(mm)	50-400	50-500	50-600		50-800
Stock Thickness(mm)	0.3~3.2	0.3-3.2	0.3-3.2		-3.2
Max.Coil Weight(kg)	3000	3000	3000	5000	5000	7000
Max.Coil O.D.(mm)	1200	1200	1200
Coil I.D.(mm)	8	8	508		508
Feed Length(mm)	~500*	~500*	~500*		~500*
Max. Line Speed(m/min)	16-24	16-24	16-24		16-24
Work Roll Number(pieces)	upper 6 lower 5	upper 6 lower 5	upper 6 lower 5		upper 6 lower 5
Feed Roll Number(set)	1	1	1		1
Main Motor(kw)	AC2.9	AC2.9	AC4.4		AC4.4
Mandrel Expansion	hydraulic	hydraulic	hydraulic		hydraulic
Reel Motor(kw)	1.5	1.5	1.5	2.2	2.2	3.7
Power(V)	3 Phase 220V/380V/50HZ
Operating Air(Mpa)	0.49	0.49	0.49		0.49

Straigtening performance:

tock Thicknees (mm)	Stock Width (mm)
0.3	400	500	600	800
0.4
0.6
0.8
1.0
1.2
1.4
1.6			470	470
1.8			400	400
2.0			360	360
2.3	300	300	300	300
2.5	230	230	230	230
2.8	150	150	150	150
3.2	110	110	110	110

*1:(Pneumatic):Option in case of pneumatic mandrel expansion is provi
Nc Servo Punch Feeder Hardware Parts Machining Accuracy Straightening Metal

1. Pre-Sales Service:We have professional designers to meet the different requirement of our customers.
2. After-Sales service:We have an efficient team to meet 24*7 all day service.
3. Full-Service:Actively cooperate with customers to deal with problems in equipment using.
4. Engineers can provide service machinery overseas.
