Feeder leveling feeding accuracy is high, Dongguan Ruihui robot manufacturing
1. The three-in-one feeder has a wider application range and can process thick plates and high-strength thick plate materials that cannot be processed by the split stamping production line. The maximum leveling material thickness can reach 12mm, and it can be applied to the processing and production of various high-strength plates, so that the processing and production of thick plate materials can also be automated.
2. The three-in-one feeder feeds the flattening with higher precision and the finished product quality is better. The three-in-one feeder integrates the material rack, leveling and feeding into one machine, which makes the machine's matching achieve complete synchronization. The control of the PLC closed-loop system truly ensures the leveling feeding accuracy.
3. Compact structure and small footprint. The three-in-one feeder combines the three machines together, the whole body is only about 4 meters, and there is no need for the waiting area. The discharging bracket device directly enters the punching mold inlet, which will undoubtedly be extremely Great savings in floor space.
4. Convenient operation, real automation, greatly saving labor and reducing labor intensity. The three-in-one feeder is a device that truly realizes automatic operation. The feeding, feeding, material blocking, folding, leveling, feeding and refueling are all controlled by one person on a separate console. Completed, greatly saving labor and reducing labor intensity.
5. imported core components, a complete lubrication system, comes with self-test procedures, the failure rate is extremely low. The whole core components of the three-in-one feeder are imported from Germany and Japan, and the complete lubrication system and self-testing program make the machine wear very little, the failure rate is extremely low, and the maintenance is very simple.
Specification:
| Model | MAC2-400 | MAC2-500 | MAC2-600 | MAC2-800 |
| Stock Width(mm) | 50-400 | 50-500 | 50-600 | 50-800 |
| Stock Thickness(mm) | 0.3~3.2 | 0.3-3.2 | 0.3-3.2 | -3.2 |
| Max.Coil Weight(kg) | 3000 | 3000 | 3000 | 5000 | 5000 | 7000 |
| Max.Coil O.D.(mm) | 1200 | 1200 | 1200 | |
| Coil I.D.(mm) | 8 | 8 | 508 | 508 |
| Feed Length(mm) | ~500* | ~500* | ~500* | ~500* |
| Max. Line Speed(m/min) | 16-24 | 16-24 | 16-24 | 16-24 |
| Work Roll Number(pieces) | upper 6
lower 5 | upper 6
lower 5 | upper 6
lower 5 | upper 6
lower 5 |
| Feed Roll Number(set) | 1 | 1 | 1 | 1 |
| Main Motor(kw) | AC2.9 | AC2.9 | AC4.4 | AC4.4 |
| Mandrel Expansion | hydraulic | hydraulic | hydraulic | hydraulic |
| Reel Motor(kw) | 1.5 | 1.5 | 1.5 | 2.2 | 2.2 | 3.7 |
| Power(V) | 3 Phase 220V/380V/50HZ |
| Operating Air(Mpa) | 0.49 | 0.49 | 0.49 | 0.49 |
Straigtening performance:
| tock Thicknees (mm) | Stock Width (mm) |
| 0.3 | 400 | 500 | 600 | 800 |
| 0.4 |
| 0.6 |
| 0.8 |
| 1.0 |
| 1.2 |
| 1.4 |
| 1.6 | 470 | 470 |
| 1.8 | 400 | 400 |
| 2.0 | 360 | 360 |
| 2.3 | 300 | 300 | 300 | 300 |
| 2.5 | 230 | 230 | 230 | 230 |
| 2.8 | 150 | 150 | 150 | 150 |
| 3.2 | 110 | 110 | 110 | 110 |
*1:(Pneumatic):Option in case of pneumatic mandrel expansion is provide
1. Pre-Sales Service:We have professional designers to meet the different requirement of our customers.
2. After-Sales service:We have an efficient team to meet 24*7 all day service.
3. Full-Service:Actively cooperate with customers to deal with problems in equipment using.
4. Engineers can provide service machinery overseas.
